SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
17.25” – 17.3125”
|
|
INTERNAL DEPTH
|
13.984” -14.047”
|
|
INTERNAL WIDTH
|
7.4375” - 7.4687”
|
|
EXTERNAL LENGTH
|
18.594“ MAX
|
|
EXTERNAL WIDTH
|
8.296” MAX
|
|
EXTERNAL HEIGHT
|
14.594” MAX
|
|
US ARMY DRAWING NO.
|
7258943
|
|
SPECIFICATION
|
MIL-S-23389B
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000 M4AA 407 A13 B13 C12 F19
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
17.25” – 17.3125”
|
|
INTERNAL DEPTH
|
13.984” -14.047”
|
|
INTERNAL WIDTH
|
8.625” - 8.656”
|
|
EXTERNAL LENGTH
|
18.594“ MAX
|
|
EXTERNAL WIDTH
|
9.5” MAX
|
|
EXTERNAL HEIGHT
|
14.594” MAX
|
|
US ARMY DRAWING NO.
|
10542565
|
|
SPECIFICATION
|
MIL-S-50312
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000 M4AA 407 A13 B13 C12 F19
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
12.87” – 12.93”
|
|
INTERNAL DEPTH
|
13.343” -13.413”
|
|
INTERNAL WIDTH
|
5.009” - 5.039”
|
|
EXTERNAL LENGTH
|
14.34“ MAX
|
|
EXTERNAL WIDTH
|
5.72” MAX
|
|
EXTERNAL HEIGHT
|
13.87” MAX
|
|
US ARMY DRAWING NO.
|
12576143
|
|
SPECIFICATION
|
MIL-C-70998
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000 M4AA 407 A13 B13 C12 F19
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
17.25” - 17.31”
|
|
INTERNAL DEPTH
|
9.5” - 9.563”
|
|
INTERNAL WIDTH
|
5.50” MIN
|
|
EXTERNAL LENGTH
|
18.76” MAX
|
|
EXTERNAL WIDTH
|
6.36” MAX
|
|
EXTERNAL HEIGHT
|
10.39” MAX
|
|
US ARMY DRAWING NO.
|
12564414
|
|
SPECIFICATION
|
MIL-C-70842
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
11” - 11.03125”
|
|
INTERNAL DEPTH
|
12.625” - 12.6406”
|
|
INTERNAL WIDTH
|
5.5625” - 5.5781”
|
|
EXTERNAL LENGTH
|
12“ MAX
|
|
EXTERNAL WIDTH
|
6.09375” MAX
|
|
EXTERNAL HEIGHT
|
13.359375” MAX
|
|
US ARMY DRAWING NO.
|
9234843
|
|
SPECIFICATION
|
MIL-DTL-3060
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000 M4AA 407 A13 B13 C12 F17
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
11.875” - 11.907”
|
|
INTERNAL DEPTH
|
8.175” - 8.251”
|
|
INTERNAL WIDTH
|
6.75” - 6.766”
|
|
EXTERNAL LENGTH
|
12.906” MAX
|
|
EXTERNAL WIDTH
|
7.297“ MAX
|
|
EXTERNAL HEIGHT
|
8.906” MAX
|
|
US ARMY DRAWING NO.
|
9396178
|
|
SPECIFICATION
|
MIL-C-70628
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000 M4AA 407 A13 B13 C12 F17
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
17.25” - 17.3125”
|
|
INTERNAL DEPTH
|
13.98” - 14.04”
|
|
INTERNAL WIDTH
|
9.75” - 9.78”
|
|
EXTERNAL LENGTH
|
18.594” MAX
|
|
EXTERNAL WIDTH
|
10.594” MAX
|
|
EXTERNAL HEIGHT
|
14.594” MAX
|
|
US ARMY DRAWING NO.
|
986AS106
|
|
SPECIFICATION
|
PQAR-986AS106
|
|
COATING
|
POWDER COATED
|
|
PRE-TREATMENT
|
ZINC PHOSPHATE TO TT-C-490
|
|
COLOUR
|
ANY RAL OR FED STD COLOR
|
|
GASKET SPEC
|
ASTM D2000 M4AA 24 A13 B13
|
|
SPECIFICATIONS:
|
|
|---|---|
|
INTERNAL LENGTH
|
12.00” - 12.04”
|
|
INTERNAL DEPTH
|
13.13” - 13.29”
|
|
INTERNAL WIDTH
|
5.56” - 5.60”
|
|
EXTERNAL LENGTH
|
13.3071” MAX
|
|
EXTERNAL WIDTH
|
6.2992” MAX
|
|
EXTERNAL HEIGHT
|
13.9764” MAX
|
|
UK MOD DRAWING NO.
|
SV575A
|
|
SPECIFICATION
|
L9994
|
|
COATING
|
WET PAINT IAW L9994
|
|
PRE-TREATMENT
|
ETCHING PRIMER OR ZINC PHOSPHATE
|
|
COLOUR
|
BS-499 SERVICE BROWN
|
|
GASKET SPEC
|
CHLOROPRENE RUBBER TO BS2752
|
